5 Ton Hino Crane Truck

Price Contact
Promotion
  • Physical damage coverage and civil insurance

  • Co operative badge

  • GPS

  • 7 year maintanance

  • Free vehicle checking fee

  • Vehicles instalment 80%

    Cabin Chassis Hino FC9JLTC
    Cranes Tadano TM - ZE303MH
    Section 3
    Max lifting power 3.030 kg x 2,5 m
    Min lifting popwer 930 kg x 7,5 m
    Total payload 11.000 kg
    Payload after body instalation 5.250 kg
    Inner Dimention 6.120 x 2.340 x 575 mm



Call Now
Total payload (Kg)11.000
EngineJ05E - UA
TypeDiesel engine HINO J05E-UA, 4-cylinder in-line, turbo charged and intercooled
Max Power (ISO NET)180 PS - (2,500 round/minutes)
Max Torque (ISO NET)530 N.m - (1,500 round/ minutes)
Bore & Stroke (mm)112 x 130



Series 500 series
Model FC9JLTC
Gross weight 11.000 kg
Pay load 5.250 kg
Engine model
Diesel engine HINO J05E-UA, 4-cylinder in-line, turbo charged and intercooled
Max Power (ISO NET)
180 PS - (2,500 round/minutes)
Max Torque (ISO NET)
530 N.m - (1,500 round/ minutes)
Piston displacement (cc)
5,123
Fuel injection
Electronic control common rail type
Crane model
Tadano TM-ZE303MH
Crane capacity
3,030 kg - 2.5 m
Crane mass
Approx. 1,160 kg (includes standardized mounting parts)
Hook Stowing Device
Mechanically stowed beneath boom top portion
